MK-62

Fully automatic horizontal strapping machine for cans

• Can be integrated into most production lines
• Ultrasonic sealing system with electronic self-calibration
• High sealing tension due to a minimum distance from package to sealing unit
• Operation in the control cabinet door
• Potential-free contacts to upstream and downstream machines
• Infinitely adjustable strap tension via touch panel
• Low-wear, controlled strap path system
• Automatic strap loop ejection when machine cycles without bundle
• Vertical frame stroke up to 800mm
• Horizontal frame stroke adjustable from 0-100 mm
• Movement of strap guid frame via belt drive
• Automatic strap threading
• Strap end detection with ejection of remaining strap
• Wear-free DC drive, brushless motor technology
• 10 freely configurable programs with up to 10 strapping positions
• Inserts for horizontal product alignment
